C60X5
The 2U general-purpose server built on the Intel® Eagle Stream platform
Powerful
- Powered by Intel® Xeon® 4th/5th Gen Scalable Processors (up to 350 W TDP)
- 32 DIMM slots, up to 8 TB DDR5-5600 RDIMM
- Intel® AMX built-in for AI acceleration
- Versatile configurations for diverse applications
Scalable
- Up to 12 × 3.5″ or 28 × 2.5″ HDDs
- Up to 8 × PCIe slots + 1 × OCP 3.0
- Up to 2 × DW GPU slots for enhanced compute
Optimized
- 1+1 redundant PSUs for continuous uptime
- Efficient thermal design for stable performance
- Remote management for simplified operations
Overview
The C60X5 is a 2U general-purpose server built on the Intel® Eagle Stream platform, supporting 4th and 5th Gen Intel® Xeon® Scalable Processors with up to 64 CPU cores — delivering up to 60% more performance compared to the previous generation.
With support for DDR5 memory and PCIe 5.0, the C60X5 provides outstanding bandwidth and scalability for modern compute-intensive workloads.
Application
Cloud & Virtualization, Big Data Analytics, AI Inference
Technical Specifications
| CPU | 2* Intel® Xeon® 4th&5th SPR/EMR Processors up to 350W |
| Memory | Up to 32* DDR5 DIMM Slots, up to 5600MT/s, support RDIMMs & LRDIMMs |
| Storage | Front : 12* LFF SATA/SAS/NVMe 24* SFF SATA/SAS/NVMe Internal : 2 * 2280 M.2 (SATA/NVMe) onboard slots Rear : 4 * SFF SATA/SAS/NVMe |
| PCIe Extension | Option1: 2* PCIe5.0 x16 FHFL + 4* PCIe4.0 x8 FHHL Option2: 2* PCIe5.0 x16 FHHL + 2* PCIe4.0 x8 FHHL + 2* PCIe4.0 x6 FHHL OCP3.0 |
| Enclosure Management | BMC: AST2600, 1* dedicated RJ45 MGMT port |
| IO | FrontIO: 2* USB3.0 Type-A Receptacles 1* PWR BTN with 1* PWR Indicator 1* Status LED 1* VGA 1* UID button & LED RearIO: 2 * USB3.0 Type-A Receptacles 1 * VGA 1 * UART Port Over RJ45 1* UID button & LED 2 * 1000 BASE-T onboard LAN Ports 1 * GbE MGMT Port (Not both Front MGMT Ports) |
| Cooling | 4* 8056 FANs, N+1 Redundancy |
| Operating Temp. | 5oC – 35oC |
| PSU | 1+1 Redundancy (1300W/1600W/2000W) |
| Dimension | 86mm(H)×447mm(W)×815mm(D) |
